INGUN Gold-plated Test Probe Receptacle (socket) KS-003 30G
Test Probe Socket KS-003 30G Receptacle Solder Type, KS-003 30 G Socket for Spring-loaded Test Probe
The KS-003 30G is a gold-plated test probe receptacle (socket), manufactured by INGUN. It is designed to be soldered into a printed circuit board (PCB) and provides a socket for a compatible spring-loaded test probe (e.g., GKS-003 series).
Specifications
| Manufacturer | INGUN |
| Type of Accessory | Test probe socket (receptacle) |
| Connection Type | Solder |
| Contact Plating | Gold-plated |
| Total Length | 30.23 mm |
| Outer Diameter | 2.36 mm |
| Collar Diameter | 2.49 mm |
| Application | For use with test needles/probes in In-Circuit Testing (ICT) and Function Testing (FCT) |
| Compatible Probe Series | GKS-003 |
Key Features
- Application: Primarily used in test fixtures for function and burn-in tests of electronic circuit boards.
- Low Resistance: Features a typical internal resistance (Ri) of less than 10 mOhm.
- Mounting: Designed for press-in mounting into a mounting hole diameter of 2.33-2.34 mm (in FR4 material) and has a press ring for variable installation height.
- Durability: The gold plating offers good chemical resistance and protection against oxidation and corrosion.
