KTR3-R-25 displacement sensor
Key Specifications & Features

• Measuring Range: 25 mm
• Design Type: Miniature size with a built-in self-returning spring and roll-wheel or push-rod gauge head
• Measurement Principle: Resistive potentiometer
• Resistance Value: Typically 1KΩ to 5KΩ (depending on the exact sub-variant
• Linear Accuracy / Linearity: ± 0.05% to ± 0.1%
• Repeatability: 0.01 mm
• Protection Class: IP65 (dust and water resistant)
• Output Options: Analog resistive, DC voltage, or converted 0–5V, 0–10V, or 4–20 mA signals
• Common Applications: Structural crack monitoring, small automation machinery, tension/speed adjusters, bottle-blowing machines, robotics, and precision position feedback.

Are you looking for pricing, wiring diagrams, or a specific brand alternative (such as Miran or SOP) for this 25 mm sensor
