Snap-action Micro Switch KW4A-A Limit Switch
Miniature Micro Switch KW4A-A 125/250V AC Push, Plunger, or Lever Limit Switch
The KW4A-A micro switch, part of the KW4A series by Dongnan, is a compact, highly reliable push or plunger-type switch widely used in home appliances and electronic equipment.
Specifications
| Current Rating | 5A to 16A (model dependent) |
| Voltage Rating | 125/250V AC |
| Switch Type | Push, Plunger, or Lever (model dependent) |
| Material/Body | Plastic |
| Dimensions | 19.8 x 10.8 x 6.4 mm (approx.) |
| Electrical Life | ≥ 10,000 cycles |
| Mechanical Life | ≥ 1,000,000 cycles |
| Operating Speed | 0.1mm - 1m/s |
| Safety Approvals | UL, cUL, VDE, TUV, ENEC, DEMKO, CE, EK CQC |
| Application | Home appliances, electronic equipment, automatic machines, communication equipment, car electronics, etc. |
Product Details
The KW4A-A is part of the KW4A series of micro switches.
- Type: It is a snap-action micro switch, characterized by a small contact gap, quick action, high sensitivity, and small operating travel.
- Application: These switches are broadly used in home appliances (such as vacuum cleaners and water heaters), electronic equipment, automatic machines, communication equipment, and car electronics.
