LA38-203209B Specialty Electrical Switches & Relays in Electrical Switche
Technical Specifications
- Current Rating (\(I_{th}\)): 10A
- Insulation Voltage (\(U_{i}\)): 380V to 660V AC (depending on the specific manufacturer variant)
- Panel Cutout Diameter: Standard 22mm (0.87 inches)
- Maximum Panel Thickness: Up to 6mm (0.24 inches)
- Terminal Type: 4 screw terminals
- Contact Type: 1 Normally Open (NO) + 1 Normally Closed (NC), configured as a Double-Pole Single-Throw (DPST) design
Common Physical Layouts
The "LA38-203/209B" designation typically refers to the underlying electrical contact block assembly, which means the outer operator head can vary based on your specific machine configuration:
- Rotary Selector Switch: The most common variation features a 2-position latching (self-locking) knob or turn-switch. It functions as a manual/automatic toggle or a standard ON/OFF maintenance switch.
- Push Button Switch: Often deployed as a heavy-duty, flat-head or mushroom-head control button.
