LA42DWQ-22 10K Potentiometer

LA42DWQ-22 10K Potentiometer
Technical Specifications

• Resistance Value: 10K Ohms (±10% tolerance).
• Mounting Hole Diameter: Standard 22 mm (0.87 inches).
• Power Rating: Typically 0.5W to 2W depending on the manufacturer.
• Ingress Protection: IP65 rated, making it dust-tight and resistant to water splashes.
• Operating Temperature: -20°C to +55°C (some industrial variants handle higher ranges).
• Termination: 3 screw terminals, eliminating the need for soldering. Key Design Features

• Integrated Scale: The bezel features a built-in dial reading from 0 to 10 with 0.5 increments, allowing precise visual adjustments without needing an external legend plate.
• Standard 22mm Cutout: Fits into standard industrial control pnel push-button slots, easing integration alongside pilot lights and emergency stops.
• Solderless Wiring: Screw terminals provide a mechanically secure connection that handles machine vibrations better than simple soldered joints
