LC1F330 Schnider contactor

LC1F330 Schnider contactor
Key Specifications

• Brand/Series: Schneider Electric / TeSys F
• Poles & Contacts: 3 Poles (3 NO - Normally Open power pole contacts)
• Rated Operational Current (\(I_{e}\)): 330A at ≤ 440V (AC-3), 400A at ≤ 440V (AC-1 thermal current)
• Motor Power Rating: Up to 160 kW at 380–400V AC-3
• Coil Support: Supplied without a coil (compatible with LX1/LX9 AC, LX4 DC, or LXE electronic coils to be ordered separately)
• Durability: Mechanical durability up to 10 million cycles; operating rate up to 2,400 cycles/hour
• Terminals: Bolt terminals for bars or cables with lugs
