LCS-2M30B-F20PNC-M12 , LCS 2M18B-F08PNC-M12-50136534 , LCS-2M30B-F20PNC-M12 LEUZE SENSOR
Key Technical Specifications
| Parameter | Specification Details |
|---|---|
| Series | Leuze LCS-2 Series |
| Sensing Distance (\(S_{n}\)) | Adjustable from 2 mm to 20 mm (Assured: 16.2 mm) |
| Output Type | Transistor PNP, Normally Closed (NC) |
| Switching Frequency | 100 Hz |
| Operating Voltage | 10–30 V DC (Rated current: 200 mA) |
| Connection Type | M12 Male Connector, 4-pin, A-coded |
| Housing Design | Cylindrical, M30 x 1.5 mm thread size |
| Installation Type | Embedded / Flush mounting |
| Material Construction | Metal housing with Polybutylene (PBT) plastic sensing face |
| Adjustment Control | Integrated multiturn potentiometer for sensitivity tuning |
| Environmental Protection | IP67 rated dust and water resistance |
| Operating Temperature | -25 °C to +70 °C |
Part Number Breakdown
- LCS-2: Capacitive sensor series
- M30: Metric 30 mm threaded housing diameter
- B: Metal housing material
- F20: Flush installation with a maximum 20 mm sensing scope
- PNC: PNP transistor output, Normally Closed function
- M12: Standard M12 plug-in connector
