LFC-10-H6 5kg load sensor

LFC-10-H6 5kg load sensor
Technical Specifications

• Rated Capacity: 5 kg max payload.
• Sensor Type: Miniature compression/button strain gauge.
• Output Signal: Millivolts per Volt (typically around 0.5 mV/V to 1.0 mV/V).
• Wiring Configuration: 4-wire interface (typically standard Excitation +/- and Signal +/- leads).
• Mounting Style: Secure screw-fastened mounting.

Core Applications

• Space-Constrained Electronics: Ideal for industrial automation and testing machines where traditional large bar load cells will not fit.
• Precision Screen Presses: Frequently utilized to monitor downforce in printing and precision tactile feedback systems.
• Small-Scale Medical/Robotics Devices: Embedded into assemblies requiring force measurement up to 5 kg.
