LLLW, W270,L5000 (MM) FUJIFILM PRESCALE
Key Specifications

• Product Type: Two-sheet type (combines A color-forming and C color-developing films)
• Pressure Range: 0.20 to 0.6 MPa (approx. 28 to 85 psi)
• Dimensions: 270 mm width x 5 m length (roll type)
• Accuracy / Precision: ±10% or less (measured via densitometer)
• Recommended Environment:
  • Temperature: 20°C to 35°C (68°F to 95°F)
  • Humidity: 35% to 80% RH
• Pressurization / Timing: Reaching time for continuous pressure is approximately 5 seconds, with a maintenance time of 2 minutes.

Common Applications

• Measuring tire pressure and contact patches
• Inspecting pressure distribution of cleaning polishes against liquid crystal (LCD) panels
• Checking contact and gasketing pressure between cylinder heads and cylinder blocks
• Evaluating delicate assembly interfaces, lamination, and micro-mechanical contact points

How to Use

1. Cut: Trim the A and C film sheets to match the dimensions of the target measurement area.
2. Combine: Place the active/textured sides of the two sheets in direct contact to form a sandwich.
3. Apply Pressure: Insert the sandwich into the interface and apply the operational force.
4. Inspect: Red color patches will appear where contact pressure occurs; evaluate the color density visually or digitize/quantify it using tools like the
