LR-W500 KEYENCE SENSOR

LR-W500 KEYENCE SENSOR
Key Specifications

• Model Number: LR-W500
• Sensing Distance: \(30\text{ to }500\text{ mm}\)
• Light Source: White LED
• Connection Type: 2-metre cable type
• Control Output: NPN or PNP open collector (selectable)
• Response Time: \(200\ \mu\text{s} \ / \ 1\text{ ms} \ / \ 10\text{ ms} \ / \ 100\text{ ms} \ / \ 500\text{ ms}\) (selectable)
• Enclosure Rating: IP65/IP67 (IEC60529) dustproof and water-resistant

Notable Features

• Adjustable Beam Spot: The beam spot diameter can be physically customized to fit your target size (approximately \(\varnothing 3.5\text{ mm}\) at \(100\text{ mm}\) up to \(\varnothing 18\text{ mm}\) at \(500\text{ mm}\)).
• Automatic Power Control: Optimizes sensor sensitivity and light intensity to accurately read glossy or highly dark targets.
• One-Touch Calibration: Simplified tuning processes make it easy to program and align targets quickly without stopping assembly lines.
• Robust Zinc Die-Cast Housing: Built to withstand high-vibration industrial environments.
