LION LRD6300 Label Sensor

LION Precision LRD6300 Capacitive Label Sensor 0.02 Response Time, 0.002″ (0.05 mm) Accuracy, NPN, PNP Open collector Outputs, +11 to 28V DC

Specification/Additional Details

• Sensor type : Capacitive
• Brand : Lion Precision
• Model : LRD6300
• Response Time : 0.02ms
• Accuracy : 0.002″ (0.05 mm)
• Outputs : NPN, PNP Open collector

• Supply Voltage : +11 to 28V DC

• Switching Frequency : 10 kHz

• Fork Width : 0.8 mm / .31"

• Bar Graph Display : Yes
