LU674-5NA Proximity sensor

Name: LU674-5NA Proximity sensor
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

LU674-5NA Proximity sensor

Technical Specifications

Sensor Type: Slot/Fork Photoelectric (Thru-beam design where an object interrupts the internal infrared light beam).
Shape/Mounting: U-type / L-type slot.
Sensing Distance / Fork Width: 5 mm.
Power Supply Voltage: \(5 \text{ VDC}\) to \(24 \text{ VDC}\) (Some variants support \(12\text{--}24 \text{ VDC}
Output Configuration: NPN (Normally Open / Normally Closed selectable depending on wiring; some multi-wire versions offer PNP compatibility).
Response Frequency: High-speed \(2 \text{ kHz}\) response time.
Protection Circuitry: Built-in short-circuit and reverse polarity protection.
Ingress Protection: IP50 rated polymer/plastic shell
