Fully Automatic Vacuum Loader Machine LV-350W-TN

Vacuum Suction Plate Loading Machine LV-350W-TN Fully Automatic Vacuum Loader,
LV-350W-TN Vacuum Suction Plate Loading Printing Machine AC220V±10v,50/60HZ Power Supply, 5kgf/cm² Air Supply Pressure, 0.5-20 meters/minute Transmission speed, Maximum 10 liters/minute Compressed air flow rate, Minimum 0.4mm Board Thickness, 200 pieces (0.6mm thick circuit board) Maximum capacity of circuit board

Specification/Additional Details

• Type : Fully Automatic
• Usage/Application : Industrial
• Model : LV-350W-TN
• Machine dimensions : 600(L)*1130(W)*1270(H)
• Working height (mm) : 920±30(std)
• Power supply : AC220V+-10v,50/60HZ

• Air supply pressure : 5kgf/cm2

• Transmission speed : 0.5-20 meters/minute

• Compressed air flow rate : Maximum 10 liters/minute

• Board Thickness : Minimum 0.4mm thickness

• Maximum capacity of circuit board : 200 pieces (0.6mm thick circuit board)

• Board size (mm) : 80*80~445*350
