M18ME1-GNX80B-S04G-EEX Balluf sensor

M18ME1-GNX80B-S04G-EEX Balluf sensor
Key Features and Specifications

• Part Number: BES02ZW (BES M18ME1-GNX80B-S04G-EEX)
• Type: Inductive Sensor (Proximity Switch)
• Housing: M18x1, Flush Mounting
• Sensing Range (): 8 mm
• Interface/Output: NAMUR (standard for hazardous areas)
• Connection: M12x1-Male, 4-pin
• Material: Nickel-free coating over brass
• Protection Rating: IP67
• Temperature Range: -20...70 °C
• Certifications/Approvals: ATEX, IECEx, FM, cCSAus, CCC Ex, UKCA
• Hazardous Area Ratings: ATEX: 1D, 1G, 2D, 2G, 3D, 3G (Suitable for Gas/Dust Zone 0/1/2) Balluff +4
