Panasonic Minas A5 MBDKT2510E AC Servo Driver

Panasonic MINAS A5 Family Servo Driver MBDKT2510E Single/3-phase 200 V, Position control type, 2.3 kHz Frequency response, 15A Power device Max. current rating, 10A Current detector current rating

Specification/Additional Details

• power : 7.5 kW
• Control method : Position control
• Frequency Response : 2.3 kHz
• Brand : Panasonic
• Model : MBDKT2510E
• Family Name : MINAS A5

• Frame Type : B-Frame

• Power device Max. current rating : 15A

• Current detector current rating : 10A

• Supply voltage : Single/3-phase 200 V

• Input power: Main circuit : Single/3-phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz

• Input power: Control circuit : Single phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz

• Parallel I/O connector: Analog signal Output : 2 outputs (Analog monitor: 2 output)

• Parallel I/O connector: Pulse signal Input : 2 inputs (Photo-coupler input, Line receiver input)

• Parallel I/O connector: Pulse signal Output : 4 outputs (Line driver: 3 output, open
• collector: 1 output)

• Communication function : USB
