MCKB-32-25M MINDMAN CLAMP CYLINDER

MCKB-32-25M MINDMAN CLAMP CYLINDER
Key SpecificationsThe MCKB series is known for its compact and lightweight design,
featuring a hard-anodized aluminum alloy body for corrosion resistance and smooth operation.

• Bore Size: 32 mm
• Stroke Length: 25 mm
• Action Type: Double acting
• Operating Fluid: Compressed air
• Operating Pressure Range: 0.1 to 1.0 MPa (approx. 1 to 9.9 kgf/cm²)
• Proof Pressure: 1.5 MPa
• Ambient Temperature: -5 to +60°C (without freezing)
• Port Size: Rc 1/8
• Available Speed Range: 50 to 500 mm/sec
• Compatible Sensor Switches: RCB, RCE, RCE1, and RDEP
• Weight (with Magnet): Approximately 456g
