MDV1238-24S 24V DC FAN

ORIX MDV1238-24S DC 24V 1.5 A Axial Fan, V Type (Variable Speed), Pulse Sensor, 224 CFM Max. Air Flow, 1.45 inH2O (100% PWM Duty), Lead Wire.
DC Cooling Fan MDV1238-24S 24V 1.5A

Specification/Additional Details

• Maximum Static Pressure : 1.45 inH₂O (100% PWM Duty)
• Fan Type : Axial Fan
• Frame Size : 4.72 in
• Thickness : 1.5 in
• Power Supply : 24 VDC
• Current : 1.5 A (100% PWM Duty)

• Type : V Type (Variable Speed)

• Function : Pulse Sensor

• Speed (r/min) : 6400 r/min (100% PWM Duty)

• Max. Air Flow : 224 CFM (100% PWM Duty)

• Noise Level : 64 dB (100% PWM Duty)

• Ambient Temperature Range : -20 °C ~ 70 °C
