MFJ40X60-10S AIRTAC VALVE

MFJ40X60-10S AIRTAC VALVE
Part Number Breakdown

• MF: Mini Cylinder series (Double acting type)
• J: Adjustable stroke style
• 40: 40mm Bore diameter (Cylinder barrel size)
• X60: 60mm Standard base stroke
• 10: 10mm Adjustable stroke range (Allows narrowing of the extension)
• S: Built-in magnet (Used for magnetic sensor switches to track piston position)

Key Technical Specifications

• Operating Fluid: Air filtered down to 40µm or less
• Operating Pressure: 0.1 to 1.0 MPa (14 to 145 psi)
• Speed Range: 30 to 800 mm/s
• Temperature Range: -20°C to 70°C (-4°F to 158°F)
• Port Connection Size: PT 1/4" thread size
• Material: High-strength, corrosion-resistant stainless steel tube

Associated ComponentsIf you are planning out the control circuit for this cylinder, you will need compatible control components:

• Control Valve: A 5/2-Way Solenoid Valve (such as the  or a manual control valve is typically used to drive this double-acting cylinder.
• Position Sensors: Compatible magnetic switches include the DMSG or CMSG sensor series.
