MGPL16-60Z SMC compact guided pneumatic cylinder

MGPL16-60Z  SMC compact guided pneumatic cylinder
Key Specifications

• Manufacturer: SMC Corporation
• Series: MGP (MGPL variant uses ball bushings)
• Function: Guided cylinder, double acting
• Bore Size: 16 mm
• Stroke Length: 60 mm
• Bearing Type: Ball bushing (indicated by 'L' in MGPL)
• Fluid: Air
• Maximum Operating Pressure: 1.0 MPa (approx. 145 psi or 10 bar)
• Minimum Operating Pressure: 0.12 MPa
• Piston Speed: 50 to 500 mm/s (for bore sizes 12-63)
• Cushion: Rubber bumper on both ends
• Lubrication: Not required (non-lube design)

Features

• Compact Design: The cylinder body is integrated into the guide body, making it a very compact unit.
• High Side Load Capability: The design, particularly the ball bushing type, offers high non-rotating accuracy and is suitable for applications involving lateral loads.
• Versatile Mounting: It offers multiple mounting surfaces, including T-slot mounting options.
• Auto Switch Capable: Grooves for mounting auto switches are provided on two sides.
