MGPM12-40Z AIR CYLINDER SMC MADE IN JAPAN

MGPM12-40Z AIR CYLINDER SMC MADE IN JAPAN
Key Specifications

• Brand/Manufacturer: SMC Corporation (Made in Japan)
• Series: MGP-Z (Compact Guide Cylinder with Slide Bearing)
• Bore Size: 12 mm
• Stroke Length: 40 mm
• Action Type: Double Acting
• Bearing Type: Slide Bearing
• Body Material: Hard-anodized aluminum alloy
• Max Operating Pressure: 1.0 MPa
• Port Size: M5 x 0.8

Features & Applications

• High Side-Load Resistance: Built with integrated guide rods to handle lateral loads and moments with high precision.
• Space-Saving Design: Utilizes the cylinder body as part of the guide structure for an ultra-compact footprint.
• Common Uses: Industrial automation for material handling, lifting, pushing, clamping, and stopping applications.
