MGPM16-10Z SMC cylinder
Key Specifications
Bore Diameter: 16 mm
Stroke Length: 10 mm
Action Type: Double acting
Bearing Type: Slide bearing (carbon steel alloy for lateral stability)
Max Operating Pressure: 1.0 MPa (10 bar / 145 psi)
Cushioning: Rubber bumper on both ends
Operating Temperature: -10°C to +60°C
Weight: Approximately 220 g
Design and Uses
Integrated guide rods isolate side loads from the piston rod.
Built for high side-load applications like material handling, lifting, pushing, and stopping.
The "Z" prefix indicates the newer lightweight design with a shorter guide rod and thinner plate.
