MGPM40-25Z-A93L SMC PNEUMATIC CYLINDER
Part Number BreakdownThe specific model code provides exact technical metrics for your equipment replacement or deployment:
- MGP: Core series designation for a Compact Guide Cylinder.
- M: Integrates a Slide Bearing (best suited for high side-impact loads and stopping applications).
- 40: Represents a 40 mm bore diameter.
- 25: Indicates a 25 mm stroke length.
- Z: Identifies the updated, lightweight body design with a shorter guide rod and thinner plate.
- A93L: Outlines a built-in D-A93 heavy-duty magnetic reed auto-switch featuring a horizontal electrical entry and a 3-meter long lead wire (signified by the "L"). [1, 2, 3, 4, 5, 6]
Core Technical SpecificationsSpecifications for this product are verified via the official distributor databases at Motion Industries and RS Components: [1, 2]
| Parameter [1, 2, 3, 4, 5, 6, 7] | Specification Metric |
|---|---|
| Action Type | Double-acting, single rod |
| Fluid Media | Compressed Air |
| Max Operating Pressure | 1.0 MPa (10 Bar / 145 PSI) |
| Ambient & Fluid Temp. | -10°C to 60°C (with no freezing) |
| Piston Speed Range | 50 to 500 mm/s |
| Cushion Type | Rubber bumpers on both ends |
| Port Thread Size | Rc 1/8 (standard for 40mm bore) |
| Total Unit Weight | Approximately 1.95 kg |
