MHMF022L1V2M Servo Motor ASSAY

MHMF022L1V2M Servo Motor ASSAY
Key Specifications

• Series / Output: MINAS A6 Series | 200 W
• Voltage: 200V (Single/Three Phase)
• Speed: 3000 RPM (Rated) / 6000 RPM (Max)
• Torque: 0.64 N·m (Rated) / 1.91 N·m (Peak)
• Encoder: 23-bit Absolute (8,388,608 resolution)
• Structure: Keyway shaft, holding brake, and oil seal

Sizing & Mounting

• Frame Size: 60 mm square flange
• Weight: ~2.1 kg
• Protection: IP65/IP67 environment-resistant

Model Number Breakdown (MHMF022L1V2M)

• MHMF: High-Inertia Servo Motor
• 02: 200W Output
• 2: 200V Class Voltage
• L: 23-bit Absolute Encoder
• V2: Straight/Threaded Shaft with Keyway and Holding Brake
• M: Standard Special Specification
