Triode MJE13003 NPN TO-126 400 Volt 1.5 A Transistor MJE 13003

Triode MJE13003 NPN TO-126 400 Volt 1.5 A Transistor,
Triode MJE13003 13003 1.5A/450V High Voltage Triode Transistor TO-92,
MJE13003 1.5A 400V NPN Power Transistor,
MJE13003 13003 TO-126 Package NPN High Power Switch Transistor

Specification/Additional Details

• Mounting Type : Through Hole
• Part Number : MJE13003
• Current : 1.5A
• Voltage : 400V
• Maximum Operating Temperature : -65 to 150 Deg°C
• Maximum Power Dissipation : - @ TA=25 Deg. C.: 1.4W (max) - @ TC=25 Deg. C.: 40.0W (max)

• Pin Count : 3

• Collector-Emitter Voltage (VCEOsus) : 400V max.

• Emitter Base Voltage : 9.0V max.

• Collector Current (cont) : 1.5A max.

• Base Current (cont) : 0.75A max.

• Emitter Current (cont) : 2.25A max.

• DC Current Gain (IC=500mA, VCE=2.0V) : 8 (min); 40 (max)

• Frequency Transistion : 10.0MHz
