Omron MJN1C-N-DC12 General Purpose Relay

Omron General Purpose Relay MJN1C-N-DC12 SPDT 10A 12V DC 5 Pins/Terminals,
Omron MJN1C-N-DC12 General Purpose Relay

Specification/Additional Details

• Mounting Style : Socket
• Rated load : 6000VA, 280W (Max Switching)
• Brand : Omron
• Model : MJN1C-N-DC12
• Coil Voltage : 12V DC
• Contact Form : SPDT (1 Form C)

• Contact Rating (Current) : 10 A

• Switching Voltage : 600VAC, 28VDC - Max

• Coil Current : 100 mA

• Coil Type : Non Latching

• Termination Style : Plug In, Quick Connect - 0.187" (4.7mm)

• Contact Material : Silver Alloy

• Coil Resistance : 120 Ohms

• Operate Time : 20 ms

• Release Time : 10 ms
