MKB16-10RZ Pneumatic valve

MKB16-10RZ Pneumatic valve
Key Specifications

• Type: Rotary clamp cylinder (swing clamp)
• Bore Size: 16 mm
• Stroke Length: 10 mm
• Action Type: Double-acting with built-in magnet
• Rotation Direction: Clockwise rotation (unclamp to clamp)
• Port Size: M5 x 0.8 metric thread
• Operating Pressure Range: Up to 1.0 MPa (10 bar / ~145 psi)
• Cushioning: Rubber bumper
• Mounting: Through-hole / both ends tapped standard

Features

• Designed with an allowable moment of inertia up to 3 times higher than standard predecessors.
• Small auto switches can be flush-mounted on any of the four sides.
• Frequently used for holding parts securely in industrial automation and welding setups.
