MKB40-10LZ cylinder SMC

MKB40-10LZ cylinder SMC
Part Number Breakdown

• MK: Cylinder Type (Rotary Clamp Cylinder)
• B: Mounting Style (Through-hole / Both Ends Tapped Common)
• 40: Bore Size (40 mm diameter piston)
• 10: Stroke Length (10 mm clamping distance)
• L: Rotary Direction (Left / Counterclockwise rotation during the clamp stroke)
• Z: Series Variant (Updated design featuring integrated auto-switch mounting grooves)

Key Specifications

• Clamping Force: Formidable 0.525 kN capability for secure material handling.
• Angle of Rotation: Standard 90° ± 10° swivel before linear clamping action.
• Operating Pressure: Operates seamlessly at pressures up to 1.0 MPa (10 bar).
• Switch Capabilities: Features four built-in, low-profile slots that allow flush mounting of electronic auto-switches (like the M9B) without protruding beyond the cylinder body.
• Rod Tip Shape: Standard internal female thread configuration.
