MKS2P DC24V Relay

MKS2P DC24V Relay
Key Technical SpecificationsThe following technical details are sourced from official documentation:

• Coil Voltage: 24 VDC with a resistance of 430 Ω.
• Contact Rating: 10 A at 250 VAC or 30 VDC.
• Terminals: 8-pin plug-in (octal base).
• Indicators: Includes a built-in mechanical indicator to verify contact operation.
• Durability: Rated for 100,000 electrical operations and up to 5,000,000 mechanical cycles.
• Response Time: Approximately 30 ms operate time and 20 ms release time.
