MM12-60APS-ZCk Proximity sensor

MM12-60APS-ZCk Proximity sensor
Key Specifications

• Sensing Range (\(S_{n}\)): 0 mm to 60 mm (highly dependent on the strength of the target magnet).
• Output Configuration: PNP, Normally Open (NO), DC 3-wire.
• Housing Size: M12 x 1 metric thread with a short body length of 46 mm.
• Connection Type: M12, 4-pin male connector plug.
• Operating Voltage: 10 V DC to 30 V DC.
• Switching Frequency: 1,000 Hz (1 kHz).
• Enclosure Rating: IP67 (dust-tight and water-resistant).
• Housing Material: Nickel-plated brass.

Core Technical Features

• Through-Wall Detection: This magnetoresistive sensor can seamlessly detect permanent magnets through non-ferromagnetic materials like stainless steel, aluminium, plastic, wood, or glass.
• Built-in Protection: Outfitted with robust electronic safety features, including short-circuit, reverse polarity, and power-up pulse protection.
• Visual Diagnostics: Features an integrated display LED to clearly signal its switching status.
