MQR120-24F MIBBO Power supply
Key Specifications

• Input Voltage: 100–240VAC (universal range, ~96–264VAC) / 120–370VDC
• Input Current: ~2.6A
• Output Voltage: 24VDC (adjustable range typically 24V–28V)
• Output Current: 5.0A
• Rated Power: 120W
• Efficiency: Around 87% to 90%
• Cooling: Free air convection (fanless design)
• Mounting: DIN rail TS-35 / 7.5 or 15
• Operating Temperature: -30°C to +70°C
• Dimensions & Weight: Approx. 125.2 mm × 40 mm × 113.5 mm; weight ~0.51 kg to 1.65 kg depending on casing spec
