Mitsubishi AC Servo Amplifier MR-J2S-70B-KY300 Servo Drive

The Mitsubishi MR-J2S-70B is an AC servo amplifier from the MELSERVO-J2-Super series, known for precision control in industrial automation applications.

Key Specifications

The general specifications for the Mitsubishi Electric MR-J2S-70B servo amplifier are as follows:

• Manufacturer: Mitsubishi
• Series: MELSERVO-J2-Super
• Rated Output: 0.75 kW
• Input Voltage: 3-phase 200 to 230 VAC 50/60Hz or 1-phase 230 VAC 50/60Hz
• Output Current: 4.4 A (maximum)
• Control System: Sinusoidal PWM control/current control system
• Dynamic Brake: Built-in
• Interface: SSCNET bus control or general-purpose interface options
• Speed Frequency Response: 550 Hz or higher
• Weight: Approximately 1.7 kg (3.75 pounds) to 6 Kg depending on source
• IP Rating: Typically IP20
