MR-J3-40A SERVO DRIVE

MR-J3-40A SERVO DRIVE
Key Specifications

• Power Output: 400W
• Rated Current: 2.8A
• Input Voltage: 200V to 230V AC (Single-phase or 3-phase)
• Communication: RS-422 and USB
• Encoder Resolution: 262,144 pulse/rev (18-bit)
• Dimensions: 168 mm (H) x 40 mm (W) x 170 mm (D)
• Features: Real-time auto-tuning, built-in dynamic brake, and built-in regenerative resistor

Maintenance & Safety WarningWhen wiring or inspecting the drive, always turn off the power and wait at least 15 minutes for the "Charge" lamp to fully turn off before touching the terminals. Failure to do so risks severe electric shock from residual capacitor voltage.
