Core Specifications

• Power Rating: 0.6 kW (600 Watts).
• Input Voltage: Single-phase or 3-phase 200V AC to 230V AC (50/60 Hz).
• Rated Output Current: 3.2 Amperes.
• Control Method: Sine-wave PWM control / current control.
• Speed Frequency Response: Up to 2.1 kHz for high-speed, high-accuracy positioning.
• Interface: RS-422 serial communication, analog voltage, and pulse train options.

Performance & Operational Modes

• High-Resolution Feedback: Designed to pair with absolute position high-resolution encoders to minimize vibration and enhance precision.
• Advanced Tuning: Built-in auto-tuning and advanced gain search functions dynamically handle mechanical resonance changes.
• Positioning Methods: Supports point table methods, indexer (turret) configurations, and built-in positioning functionality.
• Hardware Integration: Features a built-in dynamic brake and an integrated regenerative resistor
