MRO-RS31 -80A NGTC00, MRO-RS31 -63A NGTC00 FUSE
MRO-RS31 -80A NGTC00, MRO-RS31 -63A NGTC00 FUSE
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
MRO-RS31 -80A NGTC00, MRO-RS31 -63A NGTC00 FUSE
Technical Specifications
Both fuses share identical body styles and core voltage parameters but differ in their continuous current carrying capacities:
| MRO RS31-80A NGTC00 | MRO RS31-63A NGTC00 |
|---|---|
|
Current Rating
80 Amps [1]
|
Current Rating
63 Amps [1]
|
|
Voltage Rating
690V AC
|
Voltage Rating
690V AC
|
|
Fuse Size / Type
NT00 / NGTC00 (NH00 subclass)
|
Fuse Size / Type
NT00 / NGTC00 (NH00 subclass)
|
|
Operating Class
aR (Partial-range semiconductor protection)
|
Operating Class
aR (Partial-range semiconductor protection)
|
|
Breaking Capacity
Up to 100kA – 120kA
|
Breaking Capacity
Up to 100kA – 120kA
|
🔍 Key Features & Design
- aR Protection Class: Unlike standard gG/gL utility fuses, these are aR-class ultra-fast-acting fuses. They isolate short circuits within milliseconds to protect rectifiers, thyristors, VFDs, and inverters.
- Physical Construction: Built using a high-durability ceramic cartridge body that houses a variable cross-section pure copper or silver fuse element. The body is filled with chemically treated high-purity quartz sand to quench electrical arcs instantly.
- Blade Mount (NH00/NT00): Designed with square body knife-blade contacts for secure installation into standard industrial fuse switch disconnectors or base blocks.
