MS8910 Mastech MS 8910 Smart SMD Tester

Mastech MS 8910 Smart SMD Tester

• Display Resolution: 3000 counts high-contrast LCD screen.
• Resistance Range: \(300\Omega\) to \(30\text{M}\Omega\) (Accuracy: \(\pm1.0\% + 2\)).
• Capacitance Range: \(3\text{nF}\) to \(30\text{mF}\) (Accuracy: \(\pm2.0\% + 3\)).
• Diode Check: Open voltage of \(2.8\text{V}\) and testing current of \(2\text{mA}\).
• Continuity Buzzer: Sounds dynamically when resistance drops below \(30\Omega\).
• Power Source: One \(3\text{V}\) CR2032 button cell battery.
• Dimensions & Weight: Ultra-lightweight build weighing roughly

• Auto-Scanning Mode: The unit automatically recognizes whether it is gripping a resistor, capacitor, or diode, dynamically applying the correct testing metrics without manual switching.
• Manual Override: Users can toggle functions manually using the single "FUNC" push-button if specific isolating diagnostics are required.
• Premium Contact Tips: Equipped with non-magnetic steel, gold-plated test pins that systematically lower baseline contact resistance and protect against oxidation rust.
• Power Efficiency: Features a built-in Auto Power Off (APO) function that shuts down the system automatically if left idle for longer than 10 minutes.
• Data Hold: Freezes the current active reading on-screen to assist with tight component spaces.
