MT-2 motor brake rectifier module
Key Specifications

• Input Voltage: AC 200V / 220V
• Output Voltage: DC 90V
• Function: Steps down and rectifies AC power from the motor circuit to release or engage the DC magnetic brake coil safely and rapidly.
• Common Variants:
  • MT-2: Standard AC200/220V input to DC90V output.
  • MT-2D: Higher voltage version with AC400/380V input to DC180/170V output.
  • Main Uses
    • Cranes and hoists
    • EOT (Electric Overhead Traveling) cranes
    • Industrial machinery and conveyor drives requiring fast, controlled stopping [
