MU10X25S Airtek cylinder

MU10X25S Airtek cylinder
Core Specifications

• Series / Type: MI Series (Stainless Steel Mini Cylinder, conforms to ISO 6432)
• Action Type: Double-Acting (uses compressed air to both extend and retract)
• Bore Diameter: 10 mm
• Stroke Length: 25 mm
• Operating Pressure: 0.15 to 1.0 MPa (approx. 22–145 psi or 1.5–10 Bar)
• Operating Temperature: -20 °C to 70 °C
• Speed Range: 30–800 mm/s
• Cushioning: Built-in fixed bumper pads to reduce end-of-stroke impact
• Port Size: M5 x 0.8
