MXQ12-100 PNEUMATIC CYLINDER
Part Number Breakdown
- MXQ: High-precision air slide table series.
- 12: 12 mm bore diameter.
- 100: 100 mm stroke length.
Core Technical Specifications
- Action Type: Double-acting, dual-rod design providing twice the thrust of standard cylinders.
- Guide Mechanism: Integrated recirculating linear guide rail for high side-load capacity.
- Height Tolerance: Accurately held within ±0.05 mm.
- Material: Hardened stainless steel housing and table components.
Common Suffixes and Variants
Depending on your exact automation setup, you might see this part number with additional modification letters at the end:
- MXQ12-100Z: The updated global standard model format from SMC.
- MXQ12-100AS / AT / BT: Models configured with adjustable stroke options or metal stoppers.
- MXQ12-100BS: Equipped with built-in heavy-duty shock absorbers to cushion endpoints.
- MXQ12-100-M9N / M9B: Includes pre-installed, low-profile solid-state auto switches for position sensing.
Are you looking to replace an existing unit, source a compatible replacement brand, or find the CAD files/mounting dimensions for a new design?
