MXS12-20 Pneumatic CYLINDER

MXS12-20 Pneumatic CYLINDER
How it Works

1. Compressed Air enters one end of the cylinder through a small tube.
2. Air pressure pushes an internal piece of metal (called a piston) forward.
3. Air enters the other end to pull the piston back to its start. [1]

Key Features

• Double-Acting: The cylinder uses air pressure to both push and pull.
• Built-In Guide: It has strong metal bars on the sides. These keep heavy items from bending or twisting the shaft while moving.
• Compact Size: It fits easily into small spaces inside factory machines.

Common Uses

• Pushing items off a moving conveyor belt
• Sorting boxes in a warehouse
• Moving robotic arms in an assembly line
