MXS8-30AS cylinder SMC

MXS8-30AS cylinder SMC
Core Specifications

• Bore Size: 8 mm
• Stroke Length: 30 mm
• Action: Double acting
• Bearing Type: Cross roller bearing (isolates load from piston seals for high precision)
• Stroke Adjuster: Equipped with an adjusting bolt for fine-tuning stroke limits

Key Features

• Integrated Design: Combines an air cylinder, linear guide, and work table into a single compact profile.
• Anti-Lateral Play: Incorporates dual rods and cross roller guides to prevent side-to-side movement under loads.
• Auto Switch Capable: Includes built-in magnets for use with proximity sensors (often sold with switches like the SMC M9B or M9N).

Part Number Breakdown

• MXS: Base Air Slide Table series
• 8: 8 mm Bore size
• 30: 30 mm Stroke length
• A: Built-in stroke adjuster (adjuster on one end)
• S: Rubber bumper (for noise reduction and gentle stopping) [1, 2]
