Panasonic Safety Light Curtain NA2-N24

NA2-N24 Through-Beam Optical Sensor 18.11" (460mm) Sensing height, NPN - Open Collector, 12V ~ 24V Supply Voltage, 10ms Response Time, 5m Range,
Panasonic Slim Body Area Sensor, No. of beam channels- 24, Sensing height-460mm, NPN Output, Sensing Range 5m

Specification/Additional Details

• Sensing Technology : Optical Sensing
• Detection Range : 5 meter
• Product details : NPN output
• Sensing height : 460 mm 18.110 in
• Sensing range : 5 m 16.404 ft
• Beam pitch : 20 mm 0.787 in

• Supply voltage : 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less

• Output : NPN open-collector transistor

• Response time : 10 ms or less
