NBN30-U1-Z2 P&F sensor
NBN30-U1-Z2 P&F sensor
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
- NBN30-U1-Z2 P&F sensor
- Sensor Type: Inductive proximity sensor.
- Sensing Distance: 30 mm (non-flush installation).
- Output Type: 2-wire, Normally Open/Normally Closed (NO/NC) complementary switching function.
- Operating Voltage: 5 V to 60 V DC.
- Connection Type: Screw terminals.
- Housing Material: PA (polyamide) / metal with epoxy powder coating.
- Protection Rating: IP68 / IP69K (highly protected against dust and water).
- Switching Frequency: 0 to 150 Hz.
- Indicators: Two yellow LEDs for 360° visibility of the switching state.
- Dimensions: 40 mm (height) x 40 mm (width) x 118 mm (length).
- Approvals: cULus Listed, CSA approved, CCC certified.
