NBN4-F29-E2 PEPPERL -FUCHS SENSOR

NBN4-F29-E2 PEPPERL -FUCHS SENSOR
Technical Specifications

• Sensing Range: 4 mm rated operating distance.
• Output Type: PNP, 3-wire circuitry.
• Switching Function: Normally Open (NO) contact configuration.
• Installation: Non-flush mountable.
• Operating Voltage: 4.75 V to 30 V DC.
• Switching Current: Up to 100 mA.
• Switching Frequency: Up to 1 kHz (1000 Hz) for high-speed object processing.
• Housing Material: Robust Polyphenylene Sulfide (PPS), offering high chemical and mechanical resistance.
• Ingress Protection: IP67 rating, making it dust-tight and highly water-resistant in harsh conditions.
• Connection: Pre-cabled with a standard 2-meter PVC cable (a 5-meter version is designated as NBN4-F29-E2-5M).
• Status Indicators: Equipped with a highly visible yellow LED to display the active switching state.

Common ApplicationDue to its flat block-style body configuration, it is widely integrated into:

• Conveyor lines and automated packaging systems.
• Industrial robotics, electronic assembly lines, and machine control frames.
• Linear drive mechanisms and tight positioning setups.
