NDR-75-24 DC Power relay

NDR-75-24 DC Power relay
Key SpecificationsAccording to the official manufacturer datasheet, this unit features:

• Output Voltage: 24V DC (adjustable from 24V to 28V via front potentiometer).
• Output Current: 3.2A (rated at 76.8W total power).
• Input Voltage Range: Universal AC input (90–264V AC) or 127–370V DC.
• Efficiency: High working efficiency of up to 89%.
• Protection: Built-in protections for short circuit, overload, over voltage, and over temperature.
• Mounting: Fits standard DIN rail TS-35/7.5 or TS-35/15.
