NF63-CVF 60A 3P Controller

NF63-CVF 60A 3P Controller
Technical SpecificationsThe standard specifications are sourced from official distributor catalog data, including

• Ampere Frame (AF): 60 AF
• Rated Current (In): 60 A
• Number of Poles: 3-pole (3P) [
• Trip Unit: Fixed thermal-magnetic
• Rated Insulation Voltage (Ui): 440 V
• Short Circuit Breaking Capacity (Icu):
  • 5 kA at 380/400/415 Vac
  • 7.5 kA at 200/230 Vac
• Dimensions: 54 mm (Width) x 100 mm (Height) x 90 mm (Depth)
• Mounting style: Standard 35 mm DIN rail or screw retention

Key Features

• Compact Footprint: Features an optimized industry-standard physical size. It fits easily into small control panels.
• Economy Class Design: Part of the NF-C series. It provides basic, cost-effective circuit protection. It does not sacrifice reliability or safety standards.
• Global Approvals: Fully compliant with international standards. These include CE, CCC, TUV, and PSE regulations.
