NI50U-CK40-AP6X2-H11411 inductive proximity sensor

NI50U-CK40-AP6X2-H11411  inductive proximity sensor
Key Specifications

• Sensing Distance: 50 mm (semi-flush / non-flush mountable)
• Operating Voltage: 10 to 30 V DC
• Output Type: 3-wire DC, PNP (Normally Open)
• Switching Frequency: 250 Hz max
• Max Output Current: 200 mA
• Housing Dimensions: Rectangular block, 65 mm x 40 mm x 40 mm
• Housing Material: Plastic (PBT-GF30-V0)
• Protection Class: IP68
• Operating Temperature: -30°C to +85°C

Core Features

• uprox+ Technology: Factor 1 for all metals, meaning the sensing distance remains identical regardless of the target metal type.
• Magnetic Field Immunity: Completely immune to AC and DC magnetic fields.
• Flexible Orientation: Active face can be adjusted/oriented in 5 different directions.
• Status Visibility: High-luminance corner LEDs provide a clear view of the power and switching status from any angle.
