NJ15-30GM-N Pepperl + Fuchs inductive proximity sensor

NJ15-30GM-N Pepperl + Fuchs inductive proximity sensor
Key Specifications

• Sensing Distance: 15 mm (non-flush / unshielded installation)
• Output Type: NAMUR 2-wire DC
• Switching Function: Normally Closed (NC)
• Operating Voltage: 5 to 25 V DC (nominal 8.2 V)
• Housing Material: Stainless steel (AISI 303) threaded M30 cylinder
• Electrical Connection: Standard 2-meter cable

Features and Safety

• Safety Rating: Usable up to SIL 2 according to IEC 61508.
• Application: Built for harsh industrial automation environments requiring non-contact metal object detection.
• Purchasing: You can check stock and order units directly via

If you'd like to narrow down your options or need a specific replacement, please let me know:

• What is your application or target material?
• Do you need a specific cable length (e.g., standard 2m or extended 10m)?
• Are you looking for a flush or different housing style?
