NJ40-FP-SN-P1Proximitysensor
Technical Specifications,
According to official the core technical parameters include:
- Operating Distance: 40 mm sensing range.
- Installation: Non-flush mounting configuration.
- Output Type: 2-wire NAMUR output with a backup function (Normally Closed / NC).
- Operating Voltage: Nominal 8.2 V DC.
- Safety Rating: Usable up to SIL 3 in accordance with IEC 61508 (when paired with a qualified fail-safe interface).
- Environmental Protection: Enclosed in a robust PBT plastic block housing with an IP68 rating.
- Temperature Range: Withstands extreme ambient environments from -40 °C up to 100 °C (-40 ... 212 °F).
- Connection: Terminal compartment utilizing reliable screw terminals with an M20 x 1.5 cable gland.
Global Safety Approvals
This sensor is heavily certified for explosive and hazardous areas, boasting compliance with:
- ATEX / IECEx: Equipment protection levels Gb, Da, and Mb.
- UL / cULus: Listed for General Purpose Class 2 Power Sources.
- CCC / KCC: Approved for regional hazardous locations.
