NMB3-8GM50-E2-V1 PEPPERL+FUCHS, INDUCTIVEDC

NMB3-8GM50-E2-C-V1 PEPPERL+FUCHS, INDUCTIVEDC

• Sensor Type: Inductive
• Sensing Distance: 3 mm
• Output Type: PNP, 3-wire
• Switching Function: Normally open (NO), make contact
• Operating Voltage: 10 V to 30 V DC
• Switching Frequency: Up to 360 Hz
• Connection Type: Connector plug, M12 x 1, 4-pin
• Housing Material: Stainless steel 1.4305 / AISI 303
• Sensing Face Material: Stainless steel 1.4305 / AISI 303
• Degree of Protection: IP67
• Ambient Temperature: -25 to 75 °C (-13 to 167 °F)
• Short-circuit Protection: Pulsing
• Reverse Polarity Protection: Yes
