NRB4-12GM40-E2-C-V1 Pepperl + Fuchs sensor
Key Specifications
Sensing Distance: 4 mm (flush/shielded mounting)
Operating Voltage: 10 V to 30 V DC
Output Type: PNP, normally open (NO) contact, 3-wire
Switching Frequency: Up to 2000 Hz
Housing Material: Brass with PTFE (Polytetrafluoroethylene) coating
Protection Rating: IP67 (dust and water resistant)
Connection: 4-pin M12 x 1 connector
Special Features
Weld Immunity: Built to withstand electromagnetic interference near welding equipment.
Reduction Factor = 1: Detects all metals (steel, aluminum, brass, copper) at the exact same sensing distance.
If you'd like, let me know:
- What kind of machine or application you are installing this on?
- Whether you need a cable connector or mounting bracket recommendation?
